900mm Blade with 320mm Cutting depth Auto-walking Concrete cutter/concrete saw/floor saw

Products Details

Features 1. Brand hydraulic pump for propulsion system,having automatic lift function,reducing the operational burden. 2. Independent flow valve for control depth of cut,adjusting freely. 3. With the unique spraying system designed with water-tank,cooling water is sprayed to the blades so as to lubricate and cool the blades,enhances the service life of the blades Advantage: These Concrete cutter offer a cutting performance second to none in this class of machines. The torque transmitted to the diamond blade and the center of gravity located directly over the cutting shaft have been matched so efficiently, that the majority of the engine's power output goes there where it is needed: into the asphalt or the concrete. These two features result in cuts up to 20 per cent faster than comparable products
Model

QF-900

Engine

Briggs & Stratton ®   35Hp

Fuel Type

Gasoline

Fuel Capacity(kl)

20

Cutting Depth(mm)

320

Blade Dimension(mm)

914

Blade Rotating Speed

1800 rpm

Blade Raise/Lower System

Electro-Hydraulic Pump

Overall Dimension(LxWxH)(mm)

1620 x 800 x 1050

Shipping size(LxWxH)(mm)

1500 x 950 x 1200

Operating Weight(kg)

476

Shipping Weight(kg)

516

walking speed

22m/min

Transmission Pump

Eaton ® Hydraulic Pump

1.A variety of conrete,asphalt pavement,plaza stretching cutting 2. Concrete,asphalt pavement repairs cutting 3.All kinds of concrete cutting,grooving1. Reply to customer within 5 hours. 2. VDE, CE, GS, UL, ETL and other worldwide certifications have been obtained. 3. With 25 years manufacturing experience and more than 15 years export experience and specializes in the research and manufacture of Building machinery.Optional accessories 1. Concrete blade 2. Asphalt blade 300mm Blade for concrete  300mm Blade for asphalt   Optional Engine 1. B&S  XR2100 13.0HP    Gasoline engine 2. HONDA GX390 13HP Gasoline engine 3. ROBIN EX40 14HP Gasoline engine
